Special anti-tension floating cable for underwater robot.

Product alias: underwater robot cable, zero-buoyancy cable, floating cable, etc.

Application: the outer sheath of floating cable is made of imported PUR polymer material, and the cable is divided into flat and round shape.It is applied to underwater motor and underwater robot, and works in underwater environment.

1. According to the signal transmission requirement, the signal control line can be divided into multi-strand single core and multi-core, which is composed of core wires of different combinations;According to the requirement of isolation degree, the shielding form can be separated by single layer shielding, single layer shielding, single layer total shielding, 2 layers total shielding, etc.2. According to the usage requirements, it can be divided into longitudinal underwater robot cable form and transverse seal.

Longitudinal floating cable: used for ships to connect to the warehouse, high reliability of the use environment.Require the cable end surface (axial) to be able to withstand water pressure, in the specified test pressure and time, do not allow water seepage.Horizontal floating cable: use of underwater environment for non - piercing.The cable end face (radial) is required to be able to withstand water pressure. In the specified test pressure and time, the cable insulation resistance does not decrease, and the cable is not deformed.

Advantages of floating cable products.

1) flexibility: the flexible copper wire is used to guarantee the softness of the line.

2) bending resistance: excellent material, *** excellent pitch, ensuring that the cable is constantly bent and constantly bent;

3) shielding effect: the shielding density is as high as 85%, effective against electromagnetic interference;

5) tensile strength: special tensile fiber filling, increasing cable resistance.

6) wear-resisting: oil resistant, anti-aging, bending life more than 6 million times normal use.

7) waterproof: acid, alkali, radiation and corrosion resistance.

Floating cable structure conductor: no oxygen bare copper wire/tinned copper wire, conforming to VDE 0295 6 standard.

Insulation: imported PE materials.

Core color: conforms to VDE0293 standard.

Cable: excellent pitch cable.

Shielding: tin-coated copper braided shielding.

Jacket: imported PUR

Jacket color: yellow, orange.

Technical data working voltage: the cross section is more than 0.5mm2 300/500v;Section < 0.5mm2 300/300v.

Test voltage: 2500V/5min.

*** small bending radius:

Fixed installation: 4 * D;

Mobile installation: when the stroke is less than 10 meters, the bending radius is 5 * D. When the distance is greater than 10 meters, the bending radius is 5.5~6 * D.

Use temperature: - 50 ℃ to 110 ℃

The order requires detailed information about the various performance requirements and the use of the cable.

Starting order: 200 meters special cable.

Delivery date: about 7-10 days.

Use specifications to provide installation usage specifications.

Please contact our professional for details.

Note that the special cable features extremely high performance requirements. Please specify the application situation and environment of the cable, electrical performance requirements, external diameter requirements, strength requirements, etc. (the more detailed the better).

We design a comprehensive cable which can be used for a long time and is capable of lasting use according to the user's actual situation and equipment.

If you haven't found the right manufacturer yet, please let us try it. We will ask you for a call: 17321244168.
